MEAN WELL OWA-60E-48 fonte de alimentação driver LED impermeável IP67 60W 48V DC, entrada 90-264V AC, 1,25A, preto

Delivering 60 watts of constant-voltage power at 48V DC, the OWA-60E-48 is built for demanding outdoor and industrial LED lighting installations. Its fully sealed IP67 plastic enclosure shrugs off dust, moisture, and rough weather, while a wide 90–264V AC input ensures stable operation on virtually any mains grid worldwide.

Overview

The MEAN WELL OWA-60E-48 is a compact AC/DC switching power supply engineered for constant-voltage LED drivers, signage, and other 48V DC loads. It converts universal AC input (90–264V AC) into a tightly regulated 48V DC output with up to 90% efficiency. The unit comes with 2-wire input and output cables for straightforward wiring, and it operates silently thanks to free-air convection cooling—no fan to wear out or clog.

What stands out

• IP67 waterproof rating: fully sealed against dust and temporary immersion, ideal for outdoor use.
• Wide input range: works from 90 to 264V AC, covering 100–240V nominal mains worldwide.
• High efficiency: up to 90% conversion efficiency reduces heat and energy waste.
• Comprehensive protection: short circuit, overload, over voltage, and over temperature safeguards.
• Reliable in extreme temperatures: rated for -35°C to +70°C operation.
• Global certifications: UL, CUL, TUV, CB, CE, and FCC compliance for international projects.

Technical details

• Output power: 60 W
• Output voltage: 48 V DC (constant voltage)
• Output current: 1.25 A
• Input voltage: 90–264 V AC
• Efficiency: up to 90%
• Ripple & noise: 150 mVp-p
• Setup time: 500 ms
• Hold-up time: 16 ms
• Cooling: free air convection
• Enclosure: plastic case, IP67
• Connections: input cable (2-wire), output cable (2-wire)
• Operating temperature: -35°C to +70°C
• Protections: short circuit, overload, over voltage, over temperature
• Certifications: UL, CUL, TUV, CB, CE, FCC

Our verdict

A rugged, efficient, and globally certified 48V power supply that excels in outdoor LED and industrial applications. Its IP67 sealing, wide temperature range, and universal input make it a dependable choice for challenging environments.
