Fonte de alimentação MEAN WELL DDR-120C-24 120W 24V entrada 33,6-67,2V

The MEAN WELL DDR-120C-24 is an ultra-slim industrial DC-DC DIN-rail converter that accepts 33.6–67.2 Vdc input and delivers a regulated 24 Vdc output at up to 5 A (120 W). Its compact housing (32 mm × 102 mm × 125.2 mm) and DIN-rail mounting make it suitable for space-constrained control cabinets and industrial automation panels. The unit is RoHS compliant.

Advantages

Designed for industrial environments, the DDR-120C-24 provides a stable 24 Vdc output from a wide input range, saving space with an ultra-slim profile and standard DIN-rail installation. The converter offers a high power density (120 W) in a compact case and meets RoHS requirements for reduced hazardous substances.

Suitable for

• Industrial control cabinets and automation panels
• Telecom and network equipment requiring 24 Vdc
• Remote monitoring and distributed power systems
• Embedded systems and machinery with limited space

Key specifications

• Model: MEAN WELL DDR-120C-24 (MPN: DDR-120C-24)
• Input voltage: 33.6–67.2 Vdc
• Output voltage/current: 24 Vdc, 5 A (120 W)
• Mounting: DIN-rail
• Dimensions (W×D×H): 32 mm × 102 mm × 125.2 mm
• Compliance: RoHS
• EAN: 4021087050999

How to use

Mount the DDR-120C-24 on a standard DIN rail inside the control cabinet. Connect an appropriate 33.6–67.2 Vdc input source to the input terminals and use the output terminals to supply connected 24 Vdc loads, observing correct polarity. Verify wiring and grounding before applying power. Follow MEAN WELL wiring guidelines and ensure the connected load does not exceed 5 A.

Recommendations

Install the converter in a well-ventilated area, keep clearance around the unit for heat dissipation, and use appropriate fusing on the input and output sides. Do not exceed rated input or output limits and consult MEAN WELL documentation for detailed installation and safety instructions.
