BLUEOPTICS Check Point CPAC-TR-40SPLIT-QSFP-1M Cabo Breakout Direct Attach Copper (DAC) Compatível Passivo 40GbE para 4x10GbE QSFP+ para 4xSFP+ 1m

The BLUEOPTICS Check Point CPAC-TR-40SPLIT-QSFP-1M compatible breakout direct attach copper cable (DAC) is a high-performance, passive twinaxial copper cable designed for 40 Gigabit Ethernet connectivity. It provides a cost-effective and low-latency solution for interconnecting network equipment within racks or across adjacent racks in data centers and enterprise environments.

Advantages

This breakout cable offers a seamless upgrade path from 10GbE to 40GbE by splitting a single QSFP+ port into four SFP+ ports. It is fully compatible with Check Point CPAC-TR-40SPLIT-QSFP-1M equipment and meets MSA standards, ensuring reliable performance. The passive design consumes no power, reducing overall energy costs, while the twinaxial copper construction delivers excellent signal integrity over short distances.

Suitable for

• Data center interconnects
• Rack-to-rack and server-to-switch connectivity
• High-performance computing clusters
• Enterprise network upgrades from 10GbE to 40GbE

Key specifications

• Cable Type: Direct Attach Copper (DAC) Breakout Cable
• Connector A: QSFP+ (Quad Small Form-Factor Pluggable Plus)
• Connector B: 4x SFP+ (Small Form-Factor Pluggable Plus)
• Data Rate: 40 Gigabit Ethernet (aggregate), 4x 10 Gigabit Ethernet (per channel)
• Cable Length: 1 meter (3.3 feet)
• Cable Material: Twinaxial Copper
• Active/Passive: Passive
• Hot-Swappable: Yes
• MSA Compliant: Yes
• RoHS Compliant: Yes
• Impedance: 100 Ohm
• Supported Protocols: Ethernet

Recommendations

For optimal performance, ensure that both the switch and server ports support the required data rates and standards. This cable is ideal for short-distance connections within a rack or between neighboring racks. Always verify compatibility with your specific Check Point hardware model.
