BLUEOPTICS HPE M-Series S6B56A Transceptor QSFP56 Compatível, 200GBASE-SR4, MPO/MTP, Fibra Multimodo, 850nm, 100m, 0°C a +70°C, DDM (S6B56A-BO)

The BLUEOPTICS S6B56A-BO is a high-performance QSFP56 transceiver designed for compatibility with HPE M-Series switches. It delivers 200 Gbps data rates over multimode fiber using 200GBASE-SR4 standard, ideal for high-speed data center and enterprise networks.

Advantages

This transceiver offers reliable, cost-effective connectivity with full DDM/DOM support for real-time monitoring. Its hot-pluggable design and MSA compliance ensure easy integration and interoperability.

Suitable for

• Data center interconnects
• Enterprise network uplinks
• High-performance computing clusters
• HPE M-Series switch environments

Key specifications

• Form Factor: QSFP56
• Data Rate: 200 Gbps (4x 50 Gbps lanes)
• Optical Standard: 200GBASE-SR4
• Wavelength: 850 nm
• Max Reach: 100 meters
• Fiber Type: Multimode Fiber (MMF)
• Connector Type: MPO/MTP
• Compatibility: HPE M-Series (S6B56A)
• DDM/DOM Support: Yes
• Operating Temperature: 0°C to +70°C
• Transmitter Technology: VCSEL
• Receiver Technology: PIN
• Hot-Pluggable: Yes
• MSA Compliance: Yes
• Power Supply: 3.3V

Recommendations

For optimal performance, use with OM4 multimode fiber and ensure proper MPO/MTP connector cleaning. This transceiver is a direct replacement for HPE S6B56A.
