Cabo Panasonic para placa DLC2 integrada modelo 3SR-CABLE-DLC2 de 2 portas compatível com KX-NS700

The Panasonic cable for integrated DLC2 card 2-port (model 3SR-CABLE-DLC2) is a purpose-built interface cable designed for use with systems that accept DLC2 connections, such as the KX-NS700. It provides two dedicated ports to link DLC2 modules and peripheral devices, carrying both signalling and power where required to expand telephony functionality. The cable supports reliable connections in commercial phone installations and is intended for internal use within compatible PBX chassis or rack-mounted enclosures.

Advantages

This cable offers a factory-compatible connection specifically tuned for DLC2 modules, reducing the need for custom wiring and ensuring consistent signal integrity. Its two-port configuration allows straightforward expansion of system capacity without additional adapters. The assembly is designed to meet Panasonic compatibility requirements, helping to maintain interoperability and predictable performance in business telephony environments.

Suitable for

Key specifications

How to use

Install the cable by powering down the PBX system, aligning the connectors with the DLC2 card and the corresponding module sockets, and seating the plugs firmly until they click or are fully engaged. After connection, ensure any required module configuration or system settings are applied through the PBX management interface. Power the system back on and verify that the new ports are recognized and operational before returning the system to normal service.

Recommendations

Use this cable only with compatible Panasonic equipment such as the KX-NS700 and identical DLC2 module types. Avoid routing the cable near high-voltage lines or sources of electromagnetic interference. Do not attempt to modify the cable or connectors; replace the cable if damaged. Always follow Panasonic safety and installation guidelines and perform connections with the system powered down unless the vendor documentation explicitly allows hot-plugging.
