Cabo SAS Intel CYPCBLMEZKIT

The Intel CYPCBLMEZKIT is a 0.385 m Serial Attached SCSI (SAS) cable with Mini SAS HD connectors on both ends, engineered for high-speed, reliable connections between storage controllers and backplanes in compact server systems. Launched in Q2'21, the cable is intended for use in 1U and 2U systems to connect ROC modules to HSBP backplanes, providing a short, secure link that supports SAS data paths in dense rack environments.

Advantages

This Mini SAS HD cable offers a short signal path for reduced latency and improved signal integrity in tight server chassis. The fixed-length design and matched connector types simplify installation and reduce the need for adapters. Built to industry SAS standards, it supports stable high-speed data transfer and robust mechanical retention appropriate for repeated service and rack maintenance.

Suitable for

• Connecting ROC modules to HSBP backplanes in 1U and 2U servers
• Short-reach internal SAS connections in dense rack-mounted storage systems
• Replacing or standardizing Mini SAS HD internal interconnects in server builds

Key specifications

• Cable type: Serial Attached SCSI (SAS)
• Connector type: Mini SAS HD (Mini-SAS High Density) on both ends
• Primary length: 0.385 m (385 mm) for main ROC-to-HSBP connection
• Secondary length reference: 140 mm routing for additional ROC-to-HSBP connection points
• Designed for use in 1U and 2U server chassis
• Form factor: internal server cable for tight chassis routing

How to use

Align the Mini SAS HD connector keyed shapes with the corresponding ROC module and HSBP backplane ports and insert until the connector seats with audible or tactile engagement. Route the cable to avoid sharp bends, excessive torsion, or pinching at chassis edges; maintain the specified short lengths for proper signal performance. When servicing, disconnect by depressing any retention latch and pulling the connector straight out to avoid damaging the port or cable.

Recommendations

Install and route this internal SAS cable within the server chassis following manufacturer guidelines for bend radius and EMI clearance. Use the 385 mm lead for the primary ROC-to-HSBP path and the referenced 140 mm routing for the secondary connection points as applicable. Inspect connectors for debris or damage before insertion and handle connectors by the housing rather than the cable bundle to reduce strain.
