Caixa de comando AX para TFT de secretária até 61,00 cm (24 polegadas) da Rittal, dimensões 650×450×155 mm

Rittal AX control enclosure for desktop TFT up to 61.00 cm (24") is designed to house operator displays and control elements in industrial environments. With external dimensions of 650×450×155 mm, the enclosure provides a compact but accessible mounting area for a 24" TFT monitor, push buttons, indicators and interface modules. The enclosure supports tidy cabling and fixed mounting of the monitor while offering a finished front for operator interaction.

Advantages

The enclosure is built from robust materials to withstand industrial use and to secure mounted components. Its dimensions are optimized for desktop TFTs up to 61.00 cm (24"), enabling an integrated workstation layout that combines display and controls in one housing. The design simplifies installation and maintenance by providing a structured interior space for mounting plates and cable routing.

Suitable for

Key specifications

How to use

Install the TFT display and operator devices on the interior mounting plate or panel according to the enclosure cutout and mounting points. Route power and signal cables through designated entry points and secure them with the provided or recommended cable clamps. Place the enclosure on a desktop or secure it to a control desk surface as required; ensure the monitor is aligned and fastened to prevent movement during operation. Perform electrical and functional checks after installation to verify button, indicator and display operation.

Recommendations

For reliable operation, verify that the TFT dimensions and mounting interface match the enclosure opening before assembly. Use appropriate strain reliefs for cables and follow local electrical installation standards when connecting power and signal lines.
