Conector de cabo tripolar resistente às intempéries Sygonix SY-6748350 com terminais de encaixe, IP68, 450 V, 24 A, preto

For outdoor electrical installations where moisture and dust are constant threats, the Sygonix SY-6748350 cable connector provides a secure, weatherproof inline joint for 3-core cables. Electricians and installers rely on its IP68-rated sealing and robust plug terminals to maintain reliable connections in gardens, underground conduits, and exposed outdoor wiring.

Key specifications

• Connection type: plug terminals (3-pole)
• Rated voltage: 450 V
• Rated current: 24 A
• Ingress protection: IP68
• Cable diameter range: 5 – 12 mm
• Wire cross-section range: 0.5 – 2.5 mm²
• Housing material: PA66 (polyamide 66)
• Sealing material: silicone
• Operating temperature range: -40 °C to +105 °C
• Protection class: II (double insulated)
• Mounting type: inline
• Colour: black

Why choose it

The connector's IP68 rating ensures complete protection against dust and continuous immersion in water, making it ideal for underground or submerged applications. The generous cable diameter range accommodates a variety of cable sizes, while the wide operating temperature range guarantees performance in extreme climates. Double insulation adds an extra layer of safety for outdoor use.

Ideal use cases

• Outdoor lighting and garden power connections
• Underground cable joints for irrigation or landscape systems
• Repairing damaged outdoor cables without replacing the entire run
• Connecting cables in wet or dusty industrial environments

Good to know

The connector is supplied as a single unit and is suitable for use with cables having a diameter between 5 mm and 12 mm. It is designed for inline mounting and can be used in both outdoor and underground installations.
