Conector de tira LED 4 polos EUROLITE 50530069 para tira LED RGB de 10 mm

EUROLITE 50530069 4‑pin LED strip connector is designed for 10 mm RGB LED strips and enables a quick mechanical and electrical connection between strip segments without the need for soldering. The compact connector provides a reliable contact for four conductors, allowing users to join, repair or extend LED strips in lighting installations, stage setups or domestic projects. Its snap‑in design makes it suitable for fast adjustments and routine maintenance where time and space are limited.

Advantages

The connector offers a solder‑free connection method that reduces installation time and minimizes heat exposure to LED strips. Its compact dimensions and secure clamp ensure stable contact across all four channels of RGB strips, maintaining consistent colour output. The product is compatible with standard 10 mm RGB LED strip widths and is easy to use for both temporary and permanent wiring tasks. Designed for straightforward insertion, it helps avoid damaged pads and fragile solder joints.

Suitable for

Key specifications

How to use

Prepare the ends of the 10 mm RGB LED strips by ensuring the copper pads are clean and the strip is cut straight at the designated cut line. Lift or open the connector latch, align the strip so that each copper pad matches the corresponding metal contact inside the connector, and insert the strip fully. Close the latch to clamp the strip in place and verify that all four contacts are making secure electrical contact before powering the circuit. Repeat the same steps for the second strip segment when creating an inline joint.

Recommendations

Use the connector indoors or in protected environments, avoiding exposure to water or high humidity. Ensure power is disconnected during installation and check polarity and channel order to prevent colour mismatches. For permanent outdoor installations, consider using additional sealing or an IP‑rated connector solution.
