Conetores de emenda HEINRICH KOPP APWG Blue Electric, 2 condutores, acionamento por alavanca, cinzento, pack de 2 (327328049)

Electrical installations in junction boxes and distribution boards often require a reliable, tool-free way to join solid or stranded conductors. The HEINRICH KOPP APWG Blue Electric splicing connector provides a lever-operated connection that secures wires quickly without screws or crimping, reducing installation time and ensuring a consistent contact force.

Who is it for

Electricians and DIY installers working on building wiring, lighting circuits, or control panels who need a compact, reusable connector for 0.2–4 mm² conductors. The grey housing blends into standard installations, and the 2-piece pack suits small projects or replacements.

Main features

• Lever-operated clamping for tool-free wire termination
• Accepts solid and stranded conductors from 0.2 to 4 mm² (24–12 AWG)
• Rated for 450 V and 32 A, suitable for fixed wiring
• Polyamide housing with copper alloy contacts for durability
• Stripping length 9–10 mm, clearly marked for fast preparation
• Supplied as a pack of 2 connectors

Specifications

• Product type: Splicing connector
• Number of conductors: 2
• Connection technology: Lever-operated
• Colour: Grey
• Rated voltage (EN): 450 V
• Rated current (EN): 32 A
• Conductor cross-section (solid): 0.2–4 mm² (24–12 AWG)
• Conductor cross-section (stranded): 0.2–4 mm² (24–12 AWG)
• Stripping length: 9–10 mm
• Housing material: Polyamide (PA)
• Contact material: Copper alloy
• Max. operating temperature: 85 °C
• Flammability rating: UL94 V-2
• Mounting type: Free-hanging
• Pollution degree: 2
• Nominal impulse voltage: 4 kV
• Packaging unit: 2 pieces

Tips

Lift the lever to open the clamp, insert the stripped conductor fully, and press the lever down to lock. For stranded wires, ensure all strands are twisted together before insertion. The connector can be reopened for circuit modifications, making it reusable in temporary installations.
