DEHN 620101 elétrodo de terra profundo St/tZn 1000m tipo Z

For electrical engineers and lightning protection specialists installing deep earthing systems, the DEHN 620101 deep earth electrode provides a reliable solution for grounding in aggressive soil conditions. This 1000-meter reel of hot-dip galvanized steel strip (St/tZn) is designed for foundation earth electrodes, equipotential bonding, and lightning protection applications.

Key specifications

• Conductor type: Earthing strip / tape
• Material: Hot-dip galvanized steel (St/tZn)
• Length: 1000 m
• Width: 40 mm
• Thickness: 3.5 mm
• Cross-sectional area: 140 mm²
• Standard compliance: DIN EN 62561-2
• Type designation: Typ Z

Why choose it

The hot-dip galvanization provides high corrosion resistance, ensuring long-term durability even in aggressive soil environments. The strip form allows for efficient installation in trenches or as a foundation earth electrode, offering good electrical conductivity and high tensile strength.

Ideal use cases

• Deep earthing systems
• Foundation earth electrodes
• Lightning protection systems
• Equipotential bonding

Good to know

Supplied on a drum or reel for convenient handling and dispensing on site. Suitable for outdoor use and burial in the ground.
