DELTA Bloco de terminais de energia KG-8/POL 8 polos 16A 400V branco

The DELTA Power Terminal Block KG-8/POL is a high-quality 8-pole terminal block designed for reliable power distribution in industrial and commercial applications. Manufactured by DELTA, this terminal block ensures secure connections with screw terminals and is built to withstand demanding environments.

Advantages

This terminal block offers easy installation and maintenance thanks to its screw-type connection method. The polyamide housing provides excellent insulation and durability, while the brass contacts ensure low resistance and long-lasting performance. With a rated voltage of 400V AC and current of 16A, it is suitable for a wide range of electrical installations.

Suitable for

• Industrial control panels
• Power distribution systems
• Building automation
• Electrical cabinets

Key specifications

• Connector Type: Power Terminal Block
• Number of Poles: 8
• Rated Voltage: 400V AC
• Rated Current: 16A
• Max Wire Cross-section: 2.5 mm²
• Min Wire Cross-section: 0.5 mm²
• Connection Method: Screw Terminal
• Screw Type: M3
• Housing Material: Polyamide (PA)
• Contact Material: Brass
• Color: White
• Mounting Type: Surface Mount
• Operating Temperature Range: -25°C to +85°C
• Insulation Resistance: >100 MΩ (at 500V DC)
• Dielectric Strength: 2.5 kV (for 1 minute)
• Protection Rating: IP20
• Standards Compliance: CE Compliant

Recommendations

For optimal performance, ensure that the wire cross-section does not exceed 2.5 mm² and that the terminal block is mounted on a clean, dry surface. Always follow local electrical codes and regulations.
