Detetor de movimento infravermelho passivo ORNO OR-CR-220 360° montagem no teto branco

The ORNO OR-CR-220 is a high-quality passive infrared (PIR) motion sensor designed for ceiling surface mounting. It provides reliable motion detection with a 360° detection angle and a maximum range of 6 meters, making it ideal for indoor lighting control in residential and commercial spaces.

Advantages

Energy-saving automatic lighting control, easy installation, adjustable time delay and light sensitivity, robust polycarbonate housing.

Suitable for

• Indoor ceiling mounting in corridors, stairwells, offices, and storage rooms
• Automatic lighting control for energy efficiency
• Replacing traditional wall switches with motion-activated systems

Key specifications

• Sensor Type: Passive Infrared (PIR)
• Detection Angle: 360°
• Detection Range: Max 6m (at <24°C)
• Power Supply: 230V AC, 50Hz
• Max Resistive Load: 1200W
• Max LED/Inductive Load: 300W
• Time Delay: 10s ±3s to 15min ±2min
• Light Sensitivity: <3-2000 LUX
• Recommended Installation Height: 2.2 - 4m
• IP Rating: IP20
• Operating Temperature: -20°C to +40°C
• Standby Power Consumption: 0.5W
• Material: PC (Polycarbonate)
• Color: White
• Detection Motion Speed: 0.6-1.5 m/s
• Operating Humidity: <93% RH

Recommendations

For optimal performance, install at the recommended height and avoid placing near heat sources or air vents. Suitable for indoor use only.
