DSIT Armário de rack de servidor 47U 19" 800x1000x2260mm com porta frontal perfurada (DS8047PP)

Data centers and server rooms demand robust, secure, and well-ventilated enclosures for critical IT equipment. The DSIT DS8047PP 47U rack cabinet delivers exactly that: a spacious, floor-standing solution with a perforated front door that ensures optimal airflow while protecting your hardware. Its 800 mm width and 1000 mm depth accommodate a wide range of servers, switches, and storage devices, while the 2260 mm height provides ample vertical space for high-density deployments.

Who is it for

This cabinet is ideal for IT professionals, system integrators, and facility managers who need a reliable, secure, and scalable enclosure for enterprise data centers, server rooms, or network closets. It suits organizations that prioritize equipment cooling, physical security, and easy maintenance.

Main features

• 47U of 19-inch rack space, compliant with EIA-310-D and IEC 60297-2 standards.
• Perforated front and rear doors with approximately 80% ventilation for superior airflow.
• Removable, lockable side panels for easy access and enhanced security.
• Robust SPCC cold-rolled steel construction with a welded frame and 1000 kg static load capacity.
• Adjustable mounting rails for flexible equipment installation.
• Top and bottom cable entry with brush strips for clean cable management.
• Includes leveling feet, heavy-duty castors, and cage nuts & screws for immediate deployment.

Specifications

• Rack units: 47U
• External dimensions (WxDxH): 800 x 1000 x 2260 mm
• Material: SPCC cold-rolled steel
• Colour: Black (RAL 9005)
• Static load capacity: 1000 kg
• IP rating: IP20
• Front door: Perforated, lockable
• Rear door: Perforated, lockable
• Side panels: Removable, lockable
• Cable entry: Top and bottom with brush strips
• Mounting type: Floor standing
• Included accessories: Leveling feet, castors, cage nuts & screws (50 sets)

Tips

To maximize cooling efficiency, ensure proper airflow management by using blanking panels in unused rack spaces. Regularly inspect and tighten all screws and bolts, especially after moving the cabinet. When loading equipment, distribute weight evenly and secure heavy items at the bottom for stability.
