Eaton DILM65-XIP2X Bloco de contactos auxiliares, 2NO+2NC, montagem frontal, terminais de parafuso 106491

Expand the control capabilities of your Eaton DILM contactor with the DILM65-XIP2X auxiliary contact block. This front-mounted module adds two normally open and two normally closed instantaneous contacts, enabling reliable signaling and interlocking in industrial control circuits.

Who is it for

Electrical engineers, panel builders, and maintenance technicians who need to add auxiliary contacts to Eaton DILM or DILMP contactors in motor control applications.

Main features

• Contact configuration: 2 normally open (NO) + 2 normally closed (NC)
• Front mounting for easy installation on compatible contactors
• Screw terminals for secure wiring
• Rated operational current up to 6 A at AC-15, 230 V
• Wide operating temperature range from -25 to +60 °C

Specifications

• Contact configuration: 2NO + 2NC
• Mounting type: Front mounting
• Compatibility: Eaton DILM contactors (DILM40 to DILM72), DILMP contactors (DILMP45 to DILMP125)
• Number of poles: 4
• Terminal type: Screw terminals
• Rated operational current (AC-15, 230 V): 6 A
• Rated operational current (AC-15, 400 V): 4 A
• Rated operational current (DC-13, 220 V): 1 A
• Rated insulation voltage (Ui): 690 V
• Rated impulse withstand voltage (Uimp): 6 kV
• Degree of protection: IP20 (terminals)
• Standards: IEC/EN 60947-5-1, VDE 0660
• Operating temperature range: -25 to +60 °C
• Electrical durability (AC-15): > 1.5 x 10^6 operations
• Mechanical durability: > 10 x 10^6 operations
• Product series: DILM
• Connection method: Screw connection
• Auxiliary contact type: Instantaneous

Tips

Verify the contactor model before ordering to ensure compatibility. The DILM65-XIP2X is designed for front mounting and can be installed without tools on supported contactors.
