Eaton FAZ-C10/1-NA Disjuntor magnetotérmico (MCB), 10 A, 1 polo, característica C, 6 kA, 230 V AC, calha DIN 102087

This miniature circuit breaker (MCB) from Eaton provides reliable overcurrent protection for residential and commercial electrical installations. With a rated current of 10 A and C tripping characteristic, it is ideal for circuits with moderate inrush currents, such as lighting and socket outlets.

Advantages

The FAZ-C10/1-NA offers a high breaking capacity of 6 kA, ensuring safe interruption of fault currents. Its compact 1-module width saves space on the DIN rail, and screw terminals accommodate a wide range of conductor sizes from 1 to 25 mm² (solid). The device operates reliably in ambient temperatures from -25 °C to +75 °C.

Suitable for

• Protection of lighting and socket circuits in residential and commercial buildings
• Applications requiring C-curve tripping for moderate inrush loads
• DIN rail mounting in distribution boards

Key specifications

• Rated current: 10 A
• Number of poles: 1
• Tripping characteristic: C
• Rated voltage: 230 V AC
• Breaking capacity: 6 kA
• Frequency: 50/60 Hz
• Mounting: DIN rail
• Terminal capacity: 1-25 mm² (solid), 1-16 mm² (flexible)
• Energy limiting class: 3
• Overvoltage category: III
• Pollution degree: 2
• Rated impulse withstand voltage: 4 kV

Recommendations

For optimal performance, install this MCB in a distribution board with adequate ventilation and ensure proper torque on screw terminals. Always verify compatibility with your electrical system's voltage and frequency.
