EATON PFIM-25/2/003-G/F Interruptor diferencial (RCCB) tipo F, bipolar, 25 A, 30 mA, característica G/F 187449

Protect your electrical circuits with the EATON PFIM-25/2/003-G/F residual current circuit breaker. This 2-pole RCCB is designed for residential and commercial installations, providing reliable protection against residual currents. It features a rated current of 25 A and a residual current of 30 mA, with Type F detection for mixed-frequency loads. The G/F tripping characteristic offers short-time delay and enhanced immunity to nuisance tripping, making it suitable for circuits with electronic equipment. Mount it on a DIN rail (EN 60715) for easy integration into distribution boards.

Key specifications

• Rated current (In): 25 A
• Number of poles: 2
• Rated residual current (IΔn): 30 mA
• Residual current type: Type F
• Tripping characteristic: G/F (short-time delayed, enhanced immunity)
• Rated voltage (Ue): 230 V AC
• Rated frequency: 50/60 Hz
• Rated conditional short-circuit current (IΔc): 10 kA
• Rated impulse withstand voltage (Uimp): 4 kV
• Surge current withstand: 3 kA (8/20 µs)
• Mounting type: DIN rail (EN 60715)
• Terminal capacity (solid/stranded): 1.5 - 35 mm²
• Degree of protection: IP20 (terminals), IP40 (with enclosure)
• Operating temperature range: -25 to +40 °C
• Standards: EN 61008-1, VDE 0664 Part 10
• Mechanical endurance: 20,000 operations
• Electrical endurance: 10,000 operations
• Module width: 2 modules (35 mm)

Why choose it

This RCCB offers enhanced protection for circuits with electronic loads, thanks to its Type F residual current detection and G/F characteristic. The short-time delay prevents nuisance tripping from transient surges, while the 30 mA sensitivity ensures personal protection. Its compact 2-module width saves space in distribution boards.

Ideal use cases

• Residential distribution boards
• Commercial electrical panels
• Circuits with frequency converters or electronic ballasts
• Protection against residual currents in mixed-frequency environments

Good to know

The device complies with EN 61008-1 and VDE 0664 Part 10 standards. It is designed for DIN rail mounting and can accommodate conductors from 1.5 to 35 mm². Operating temperature range is -25 to +40 °C.
