Eaton PXL-C32/1 Disjuntor de proteção de linha (MCB), 1 polo, característica C, 32 A, 6 kA, 230/400 V AC 236062

With a rated short-circuit breaking capacity of 6 kA and a C tripping characteristic, the Eaton PXL-C32/1 handles demanding inductive loads while protecting circuits up to 32 A. Its 1-pole design fits a single 17.5 mm module on a DIN rail, making it a compact choice for distribution boards.

Overview

The Eaton PXL-C32/1 is a miniature circuit breaker (MCB) engineered for reliable overcurrent and short-circuit protection in residential and commercial installations. It operates at 230/400 V AC and 50/60 Hz, conforming to IEC/EN 60898-1. Screw terminals accept solid conductors from 1 to 25 mm² and flexible conductors from 1 to 16 mm², ensuring secure connections.

What stands out

• 32 A rated current with C curve for moderate inrush loads
• 6 kA breaking capacity for robust short-circuit handling
• Compact 1-module width saves space on the DIN rail
• Long service life: over 10,000 electrical and 20,000 mechanical operations
• IP20 terminals and IP40 housing (with cover) for basic protection

Technical details

• Rated current: 32 A
• Number of poles: 1
• Tripping characteristic: C
• Rated voltage: 230/400 V AC
• Rated short-circuit breaking capacity (Icn): 6 kA
• Frequency: 50/60 Hz
• Mounting type: DIN rail
• Terminal capacity solid: 1 - 25 mm²
• Terminal capacity flexible: 1 - 16 mm²
• Energy limiting class: 3
• Standard: IEC/EN 60898-1
• Degree of protection terminals: IP20
• Degree of protection housing: IP40 (with cover)
• Electrical life: >10,000 operations
• Mechanical life: >20,000 operations
• Connection type: Screw terminals
• Module width: 1 module (17.5 mm)
• Overvoltage category: III
• Pollution degree: 2

Our verdict

A dependable 32 A MCB with a C curve, suited for circuits with moderate inrush currents. Its compact size and solid technical specs make it a practical choice for standard electrical installations.
