EFB-Elektronik Barra de pinos de 64 pinos, passo 2,54 mm, duas filas, cinzento, THT

The EFB-Elektronik 20064.3 is a high-quality 64-pin pin header connector designed for reliable PCB connections. With a 2.54 mm pitch and dual-row configuration (2x32), this male connector is ideal for industrial and electronic applications requiring secure and durable connections. The grey PBT insulator ensures excellent insulation and flame retardancy (UL94V-0), while the brass contacts with tin plating provide reliable conductivity and corrosion resistance.

Advantages

This connector offers a robust through-hole mounting design with straight pins, ensuring easy and secure soldering to PCBs. Its compact form factor saves space on the board, and the dual-row layout allows for high-density connections. The wide operating temperature range (-40°C to +105°C) makes it suitable for demanding environments.

Suitable for

• Industrial control systems
• Automation equipment
• PCB prototyping and production
• Data communication devices
• Electronic modules and assemblies

Key specifications

• Connector Type: Pin Header Connector
• Number of Pins: 64
• Pin Pitch: 2.54 mm
• Number of Rows: Dual Row (2x32)
• Gender: Male
• Color: Grey
• Mounting Type: Through-hole
• Termination Style: Straight Pin
• Contact Material: Brass
• Contact Plating: Tin
• Insulator Material: PBT (Polybutylene Terephthalate)
• Flammability Rating: UL94V-0
• Current Rating: 1 A
• Voltage Rating: 250 V AC/DC
• Insulation Resistance: 1000 MΩ min.
• Dielectric Withstanding Voltage: 1000 V AC for 1 minute
• Operating Temperature Range: -40°C to +105°C
• RoHS Compliance: Yes

Recommendations

For optimal performance, ensure proper soldering and avoid exceeding the rated current and voltage. This connector is a reliable choice for your PCB interconnection needs.
