EFB-ELEKTRONIK Cabo Patch de Fibra Ótica LC/APC para LC/UPC Monomodo OS2 9/125µm 5m Amarelo

The EFB-ELEKTRONIK O0384.5 is a high-quality fiber optic patch cable designed for reliable singlemode connections. Featuring an LC/APC 8° angled connector on one end and an LC/UPC connector on the other, this cable ensures low insertion loss and high return loss, making it ideal for FTTH, CATV, and telecommunication networks. The 9/125µm OS2 fiber core provides excellent performance over long distances, while the LSZH (Low Smoke Zero Halogen) jacket ensures safety in indoor installations. With a length of 5.00 meters and a vibrant yellow color for easy identification, this patch cable is a professional choice for network engineers.

Advantages

This fiber optic patch cable offers superior signal integrity with APC and UPC polished connectors, minimizing back reflection and ensuring stable data transmission. The LSZH jacket reduces toxic fumes in case of fire, making it suitable for use in public buildings and data centers. The durable zirconia ceramic ferrule guarantees long-term reliability and consistent performance.

Suitable for

• FTTH (Fiber to the Home) installations
• CATV networks
• Telecommunication systems
• Data center interconnects
• Local area networks (LAN) requiring singlemode fiber

Key specifications

• Product Type: Fiber Optic Patch Cable
• Fiber Mode: Singlemode
• Fiber Class: OS2
• Core/Cladding Diameter: 9/125 µm
• Connector A: LC/APC (8° angle)
• Connector B: LC/UPC
• Cable Length: 5.00 m
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Yellow
• Insertion Loss: < 0.3 dB
• Return Loss (APC): > 60 dB
• Return Loss (UPC): > 50 dB
• Ferrule Material: Zirconia Ceramic
• Operating Temperature: -20°C to +70°C
• Standards: IEC 61754-20, TIA/EIA-604-10

Recommendations

For optimal performance, ensure connectors are clean before mating. Use appropriate patch panels and splice closures to maintain signal quality. This cable is compatible with standard LC interfaces.
