EFB-ELEKTRONIK I-V(ZN)H OS2 cabo patch duplex zipcord, 9/125µm, LSZH, amarelo, 1,8x3,7mm

The EFB-ELEKTRONIK I-V(ZN)H OS2 Duplex Zipcord Patch Cable is a high-quality indoor fiber optic cable designed for reliable single-mode transmission. With a 9/125µm core/cladding and OS2 category, it ensures low attenuation and high bandwidth for demanding network applications. The cable features a zipcord (duplex) construction with two fibers, making it ideal for patch cord manufacturing or direct termination. Its LSZH (Low Smoke Zero Halogen) outer sheath provides safety in enclosed spaces, while the yellow color ensures easy identification.

Advantages

This cable offers excellent performance with attenuation values of ≤0.4 dB/km at 1310nm and ≤0.3 dB/km at 1550nm. The aramid yarn strength members provide high tensile strength (400N) and flexibility, with a dynamic bend radius of only 18mm. The halogen-free design reduces toxic smoke in case of fire, making it suitable for use in public buildings, data centers, and offices.

Suitable for

• Indoor fiber optic installations
• Data center cabling
• LAN and WAN backbone connections
• FTTx and telecommunication networks
• Patch cord manufacturing

Key specifications

• Fiber Type: Single-Mode OS2
• Fiber Count: 2 (Duplex Zipcord)
• Core/Cladding: 9/125 µm
• Cable Designation: I-V(ZN)H
• Outer Sheath: LSZH, Yellow
• Cable Dimensions: 1.8 x 3.7 mm
• Attenuation: ≤0.4 dB/km @1310nm, ≤0.3 dB/km @1550nm
• Minimum Bend Radius: 18 mm (dynamic), 36 mm (static)
• Operating Temperature: -20°C to +70°C
• Standards: IEC 60794-2, TIA/EIA-568.3-D, ISO/IEC 11801

Recommendations

For optimal performance, use with LC or SC connectors and ensure proper cable management to maintain bend radius. This cable is compatible with standard single-mode transceivers and patch panels.
