ELFON OPTIMA OP-ON1P-G caixa de fusão de fibra ótica de sobrepor para adaptadores SC simplex, LC duplex, E2000 simplex, IP40, cinzento

Where many fiber enclosures force a compromise between size and functionality, the ELFON OPTIMA OP-ON1P-G takes a different path. This surface-mounted box keeps a low profile on the wall while still delivering proper fiber management for FTTH drops and small business connections. A single adapter slot accepts SC Simplex, LC Duplex, or E2000 Simplex, so you can match the connector style already in use without changing enclosures. The grey ABS body is UV-stabilized, meaning it won't yellow or become brittle when exposed to indirect sunlight near windows or entryways.

Highlights

• Surface-mounted enclosure for indoor fiber optic terminations
• Supports one adapter: SC Simplex, LC Duplex, or E2000 Simplex
• Accommodates up to 2 fusion splices with integrated bend radius control
• Two cable entry ports for drop cable and patchcord
• IP40 rated, grey ABS plastic with UV resistance
• RoHS compliant

In daily use

Installers appreciate the straightforward screw mounting and the organized fiber management that prevents microbends. The box is compact enough for tight spaces like apartment entryways or office telecom closets, yet provides enough room to handle two splices without strain. The grey finish blends with most wall colors, and the UV-stabilized material resists yellowing over time.

Full specifications

• Brand: ELFON
• Model: OP-ON1P-G
• MPN: OP-ON1P-G
• EAN: 5905668417199
• Enclosure type: Surface-mounted
• Adapter capacity: 1 (SC Simplex, LC Duplex, or E2000 Simplex)
• Splice capacity: Up to 2 splices
• Material: ABS plastic
• Colour: Grey
• IP rating: IP40
• Application: FTTH, FTTB, telecommunication networks
• Cable entry ports: 2
• Fiber management: Integrated bend radius control
• Mounting: Wall-mounted with screws
• Operating temperature: -5°C to +50°C
• Storage temperature: -25°C to +60°C
• Humidity: Up to 95% non-condensing
• UV resistance: Yes
• Certifications: RoHS

Final note

A discreet, durable termination point that keeps fiber runs tidy without occupying unnecessary space.
