Estrutura de caixa Rittal CP 6501.070 preto — estrutura de montagem compacta, versão preta

Rittal CP 6501.070 Black is a compact enclosure mounting frame designed for the installation of components and panels inside industrial and IT enclosures. The black finish offers a neutral aesthetic that integrates into cabinets and racks, while the compact dimensions make it suitable for space-restricted installations. This frame provides a standardized solution for securing internal assemblies and simplifying layout of electrical or electronic modules.

Advantages

The mounting frame is engineered for robust integration into enclosure interiors, offering a standardized mounting surface and consistent alignment for components. Its compact design reduces required internal space while maintaining structural stability for mounted parts. The black finish minimizes visual contrast inside cabinets and supports a neat professional appearance. The frame is compatible with common enclosure mounting practices and helps streamline installation work.

Suitable for

Key specifications

How to use

Install the frame into the enclosure according to the cabinet manufacturer's mounting points and recommended fasteners. Position the frame at the required height and secure it to the enclosure structure using appropriate screws or bolts. Once secured, mount panels, modules or terminal blocks onto the frame using compatible fasteners and ensure proper alignment and clearance for wiring and ventilation. Verify mechanical stability before energizing any installed equipment.

Recommendations

Use corrosion-resistant fasteners appropriate for the enclosure material and follow relevant installation guidelines for electrical clearance and heat dissipation. Check dimensions and mounting hole patterns of the equipment to be installed to ensure compatibility with the compact frame. For high-density installations, plan cable routing and service access to maintain safety and ease of maintenance.
