EUROLITE IP XLR Set 5-Pin ficha/conector fêmea, IP65, zamak, contactos de solda, preto 30208439

For touring sound engineers and lighting technicians who demand reliable signal integrity in challenging environments, this EUROLITE IP XLR set delivers rugged 5-pin connectivity with IP65-rated protection. The pair includes one male plug and one female socket, both engineered with die-cast zinc housings and silver-plated contacts to withstand moisture, dust, and heavy use. Whether you're wiring DMX-controlled fixtures on an outdoor stage or routing audio through a temporary broadcast setup, these connectors ensure a secure latch lock and clean solder termination for cables with diameters from 6 to 10 mm.

Key specifications

• Connector type: XLR, 5-pin
• Set contents: 1x male plug, 1x female socket
• IP rating: IP65 (dust-tight and protected against water jets)
• Housing material: Die-cast zinc, black finish
• Contact plating: Silver
• Termination: Solder contacts
• Cable diameter compatibility: 6–10 mm
• Locking mechanism: Latch lock
• Application: DMX, audio, lighting control
• Mounting type: Cable mount

Why choose it

The IP65 rating means these connectors can handle rain, splashes, and dusty backstage conditions without signal degradation. The die-cast zinc body provides excellent shielding and mechanical strength, while silver-plated contacts offer low contact resistance and corrosion resistance. The latch lock prevents accidental disconnection, making them ideal for live events where reliability is non-negotiable.

Ideal use cases

• Outdoor concerts and festivals with DMX lighting rigs
• Broadcast and AV installations in humid or dusty environments
• Permanent installations in theaters, houses of worship, or theme parks
• Rental and staging companies needing robust, field-serviceable connectors

Good to know

These connectors are designed for cable mounting and require soldering skills for assembly. The 6–10 mm cable entry accommodates a wide range of standard DMX and audio cables. For best results, use a high-quality soldering iron and follow standard XLR pinout conventions. The set is a direct replacement for worn or damaged connectors on existing cables, extending the life of your equipment.
