EXSYS EX-3607 placa controladora SATA 3 RAID, 2x SATA III + 2x M.2 NGFF, PCIe 3.0 x4, RAID 0/1/10/JBOD

Expand your system's storage capabilities with the EXSYS EX-3607, a versatile RAID controller card that adds two SATA III ports and two M.2 NGFF slots via a single PCIe 3.0 x4 interface. Powered by the ASMedia ASM1064 chipset, it delivers up to 6 Gbps per port, making it ideal for building fast, redundant storage arrays or simply adding extra drives to your desktop or server.

Advantages

The EX-3607 supports RAID 0, RAID 1, RAID 10, and JBOD, giving you flexibility to prioritize speed, data redundancy, or a balance of both. It is bootable, so you can run your operating system from an attached drive, and hot-plug support allows you to swap drives without shutting down. The card includes both standard and low-profile brackets, ensuring compatibility with a wide range of computer cases, from full towers to slim desktops.

Suitable for

• System builders and IT professionals needing to add multiple SATA or M.2 SATA SSDs to a workstation or server.
• Users who want to create a bootable RAID array for improved performance or data protection.
• Enthusiasts upgrading older systems with M.2 SATA SSDs or additional SATA drives using a PCIe x4 slot.
• Environments requiring hot-swappable drive bays for easy maintenance.

Key specifications

• Host Interface: PCI Express 3.0 x4 (compatible with x4, x8, x16 slots)
• Internal Ports: 2x SATA III (7-pin), 2x M.2 NGFF (B-Key, SATA-based)
• Data Transfer Rate: 6 Gbps per port
• RAID Levels: RAID 0, RAID 1, RAID 10, JBOD
• Controller Chipset: ASMedia ASM1064
• M.2 Form Factors Supported: 2230, 2242, 2260, 2280, 22110
• Bootable: Yes
• Hot-Plug Support: Yes
• Operating System Support: Windows 7/8/8.1/10/11, Windows Server, Linux Kernel 3.x/4.x/5.x
• Power Source: PCIe Bus Power
• Included Brackets: Standard and Low Profile
• Compliance: RoHS, CE, FCC

Recommendations

For maximum performance, use high-quality SATA III SSDs or M.2 SATA SSDs in RAID 0. For critical data, configure RAID 1 or RAID 10 to ensure redundancy. Ensure your motherboard has an available PCIe x4 or larger slot and that your case can accommodate the card's height with the appropriate bracket.
