Ferramenta de desmontagem Harting 09990000381 — ferramenta de remoção de conectores da Harting

The Demounting Tool Harting 09990000381 — connector removal tool by Harting is a compact, handheld instrument designed to remove Harting connectors and modules safely and with controlled force. It is intended for field service, maintenance, and assembly tasks where precise extraction of connectors is required without damaging housings or electrical contacts. The tool's form factor facilitates work in confined spaces and on equipment racks, making connector disassembly more predictable and repeatable.

Advantages

This demounting tool provides controlled extraction to minimise the risk of mechanical damage to connector housings and contact pins. Its handheld design ensures portability for on-site repairs and maintenance. The tool is engineered to deliver consistent performance across repeated cycles, reducing the likelihood of accidental deformation or stress on mating parts. Its build focuses on ease of handling and reliable engagement with Harting connector latching features.

Suitable for

• Field service and on-site connector removal
• Routine maintenance and equipment servicing
• Electrical and electronic assembly or disassembly tasks
• Work in confined spaces or rack-mounted installations

Key specifications

• Type: Handheld connector demounting tool for industrial connectors
• Compatibility: Designed for removal of Harting connector modules and housings
• Form factor: Compact, lightweight design for manual operation
• Material characteristics: Durable construction suitable for repeated use in service environments
• Operation: Mechanical engagement for controlled extraction without powered assistance

How to use

Position the tool so it engages the connector's designated release or latch points, applying steady force along the connector axis to disengage the module from its mating housing. Ensure the assembly is supported to prevent strain on cables or mounting hardware while extracting the connector. For best results, confirm the connector's locking mechanism is released before applying extraction force and proceed with smooth, controlled motion to avoid abrupt pulls that could damage contacts or housings.

Recommendations

Use the tool in combination with standard safety practices: disconnect power where applicable, wear appropriate personal protective equipment, and stabilise the assembly before demounting. Inspect connectors and contacts after removal for signs of damage or contamination and clean or replace parts as necessary. Store the tool in a dry, protected location to maintain its mechanical integrity.
