Ficha modular InLine 4P4C RJ10 para cravar em cabo plano, 10 unid.

The InLine Modular Plug 4P4C RJ10 is a transparent connector designed for crimping directly to ribbon cable. Supplied in a pack of 10, these RJ10 plugs are suitable for creating or repairing telephone and low-voltage signal connections where a compact 4-position interface is required.

Advantages

Transparent housing allows visual inspection of conductor alignment before and after crimping. The 4P4C (RJ10) format provides a compact, standardized interface for handset and single-line telephone wiring. Supplied as a 10-piece pack to cover multiple installations or repairs.

Suitable for

Key specifications

How to use

Prepare the ribbon cable by aligning and trimming conductors to the correct length for the 4P4C plug. Insert the ribbon cable fully into the connector so that each conductor seats in its corresponding contact. Use a compatible crimping tool designed for modular plugs to crimp the connector onto the cable, ensuring a secure mechanical and electrical connection. Inspect the transparent housing to confirm conductor alignment and proper crimp.

Recommendations

Use an appropriate crimp tool sized for small modular plugs and avoid excessive force during crimping. Verify pin alignment visually through the transparent housing and test the connection before final installation.
