GoodConnections Alcasa GC-N0120 Módulo Keystone blindado Cat.6a, RJ45 para IDC sem ferramentas, 10GBase-T, cinzento, caixa de zinco

High-speed networks demand connectors that can handle 10 Gigabit Ethernet without signal degradation or crosstalk. The GoodConnections Alcasa GC-N0120 Cat.6a shielded keystone module delivers exactly that: a robust, tool-free termination point for permanent links in data centres, offices, and industrial environments. Its die-cast zinc housing and fully shielded design protect against EMI, ensuring reliable performance up to 500 MHz.

Who is it for

Network installers, IT administrators, and system integrators who need a dependable, easy-to-terminate Cat.6a module for patch panels, wall plates, and surface-mount boxes. Ideal for 10GBase-T applications where signal integrity is critical.

Main features

• Supports 10 Gigabit Ethernet (10GBase-T) with transmission frequencies up to 500 MHz.
• Tool-free IDC termination for AWG 22–26 solid or stranded conductors – no punch-down tool required.
• Fully shielded die-cast zinc housing with 360° EMI protection; compatible with FTP/STP cabling.
• Standard keystone footprint fits all common patch panels, faceplates, and surface boxes.
• Gold-plated phosphor bronze contacts (8P8C) ensure low contact resistance and long-term reliability.
• Supports Power over Ethernet up to PoE++ (IEEE 802.3af/at/bt) for powering devices.
• Colour-coded wiring guide for T568A and T568B schemes.

Specifications

• Product type: Cat.6a shielded keystone module
• Front connector: RJ45 female (8P8C)
• Rear termination: Tool-free IDC, AWG 22–26 (solid/stranded)
• Housing material: Die-cast zinc, grey
• Contact material: Phosphor bronze with gold plating
• Transmission frequency: Up to 500 MHz
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA 568-C.2
• PoE support: PoE, PoE+, PoE++ (IEEE 802.3af/at/bt)
• Mounting: Standard keystone slot

Tips

For best performance, pair with Cat.6a shielded cable and shielded patch panels. Keep pair twists as close to the IDC contacts as possible during termination. Use a cable tie to secure the cable to the module's strain relief to prevent movement.
