Grenton módulo de saída para estores e entradas digitais (1 saída, 2 entradas) - Z-Wave Plus, montagem embutida

The Grenton Roller Shutter Output and Digital Inputs Module is a versatile Z-Wave Plus device designed for controlling roller shutter motors and monitoring digital inputs. With one relay output for AC motors and two potential-free digital inputs, this module integrates seamlessly into smart home systems, enabling automation and remote control via Z-Wave.

Advantages

This module offers reliable control of roller shutters with position reporting and calibration functions. It supports S2 security for encrypted communication and acts as a Z-Wave repeater to extend network range. Energy monitoring provides insights into power consumption, while scene activation allows for customized automation scenarios.

Suitable for

• Smart home automation systems requiring roller shutter control
• Integration with Z-Wave Plus networks for remote and automated operation
• Monitoring of digital sensors or switches via two inputs

Key specifications

• Wireless Technology: Z-Wave Plus (Gen5)
• Z-Wave Frequency: 868.42 MHz (EU)
• Power Supply: 230V AC, 50Hz
• Number of Outputs: 1 (for roller shutter motor)
• Number of Inputs: 2 (digital, potential-free)
• Max. Output Load: 1A (for motor)
• Motor Compatibility: AC motors (3-wire)
• Energy Monitoring: Yes
• Mounting Type: Flush-mount (in-wall box, e.g., Ø60mm)
• Operating Temperature: 0°C to 40°C
• Z-Wave Security: S2 Security
• Z-Wave Repeater Function: Yes
• Calibration Function: Yes
• Position Reporting: Yes
• Scene Activation Support: Yes
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure the module is installed in a standard flush-mount box and paired with a Z-Wave Plus controller. Use with compatible AC roller shutter motors (3-wire) and potential-free digital sensors.
