Hager WXF202 Moldura adaptadora Keystone para 1 módulo RJ45, Branco polar

In modern office fit-outs and residential renovations, network cabling often ends in a wall box awaiting a clean termination. The Hager WXF202 adapter frame solves this by providing a single Keystone slot that snaps into standard Hager switch ranges, allowing a tidy RJ45 data outlet without custom plates. Its 19.3 x 14.8 mm opening matches common Keystone modules, so you can insert a Cat5e, Cat6, or Cat6A jack and finish the wall with a professional look.

Key specifications

• Product type: Keystone adapter frame
• Number of module slots: 1
• Module compatibility: Keystone
• Compatible connector type: RJ45 (module not included)
• Mounting system: Hager switch programs (e.g., Kallysto, Tehalit)
• Material: Thermoplastic, halogen-free
• Colour: Polar white (RAL 9010)
• Module opening dimensions: 19.3 x 14.8 mm
• Protection class: IP20
• Operating temperature: -5 to +45 °C
• Storage temperature: -25 to +70 °C
• Mounting method: Snap-in / clip-in
• RoHS compliant: Yes

Why choose it

This frame integrates seamlessly with your existing Hager switch plates, maintaining a uniform appearance across power and data outlets. The halogen-free thermoplastic construction is safe for indoor use, and the snap-in design makes installation quick without special tools. Because it uses a standard Keystone opening, you are not locked into a specific jack category—upgrade from Cat5e to Cat6A later by simply swapping the module.

Ideal use cases

• Office workstations requiring a single RJ45 data point alongside power outlets.
• Home networking where a clean, wall-mounted Ethernet connection is needed.
• Retrofit projects where existing Hager frames can be reused for data.
• Hospitality or commercial spaces needing consistent outlet aesthetics.

Good to know

The adapter frame is sold without the Keystone jack; choose a compatible RJ45 module separately. It is designed for indoor use only (IP20) and fits Hager's Kallysto and Tehalit ranges, among others. Always verify compatibility with your specific switch series before ordering.
