HEINRICH KOPP Mecanismo de dimmer 334402008 - dimmer rotativo, branco, termoplástico, corte de fase ascendente, 20-500W, 230V, IP20

The HEINRICH KOPP Dimmer Insert 334402008 is a high-quality rotary dimmer designed for flush-mounted installation. It features a rotary control with push-button on/off function and uses leading edge (phase cut) dimming principle, compatible with incandescent lamps, HV halogen lamps, and dimmable electronic transformers. The housing is made of durable thermoplastic in white, with protection class IP20. It includes screw terminals for easy connection and offers overload, short-circuit, and thermal protection. CE certified.

Advantages

Reliable dimming performance with overload, short-circuit, and thermal protection. Easy installation with screw terminals. Compact design suitable for standard flush boxes.

Suitable for

• Incandescent lamps
• HV halogen lamps
• Dimmable electronic transformers (leading edge compatible)

Key specifications

• Product Type: Dimmer Insert
• Dimmer Type: Rotary Dimmer
• Control Method: Rotary with Push-Button (On/Off)
• Dimming Principle: Leading Edge (Phase Cut)
• Power Rating: 20 - 500 W
• Operating Voltage: 230 V AC
• Frequency: 50 Hz
• Installation Type: Flush-mounted
• Housing Material: Thermoplastic
• Product Color: White
• Protection Class: IP20
• Connection Type: Screw terminals
• Certification: CE

Recommendations

Ensure compatibility with your load type. For LED loads, use only dimmable LEDs and check minimum load requirements. Professional installation recommended.
