JUNG AL 2990 TV AN tampa para tomadas de antena 1 tomada, alumínio lacado, série LS, antracite

In residential and commercial installations where a single antenna cable must feed multiple receivers, the Jung AL 2990 TV AN provides a flush-mounted through-socket with three outputs: TV (IEC male), RF (IEC female), and SAT (F-connector female). The anthracite cover matches Jung's standard range, and the metal insert ensures mechanical stability.

Key specifications

• Outputs: TV (IEC male), RF (IEC female), SAT (F-connector female)
• Frequency range TV/RF: 5 – 862 MHz
• Frequency range SAT: 950 – 2200 MHz
• Tap loss TV/RF: 10.0 dB
• Tap loss SAT: 10.0 dB
• Through loss TV/RF: 1.5 dB
• Through loss SAT: 2.0 dB
• Shielding class: A
• DC passage for SAT: Yes
• Impedance: 75 Ohm
• Material: Thermoplastic cover, metal insert
• Mounting type: Flush-mounted (Unterputz)

Why choose it

The socket supports single-cable and multi-switch systems, with DC passage for SAT allowing remote powering of LNBs. Its class A shielding reduces interference, and the anthracite finish blends with modern interiors.

Ideal use cases

• Distributing TV, radio, and satellite signals to multiple rooms
• Connecting receivers in home entertainment setups
• Commercial AV distribution in hotels and offices

Good to know

The socket is designed for flush-mounted installation in standard wall boxes. The metal insert provides durability for frequent connections.
