LevelOne fonte de alimentação industrial 24V DC, 75W, montagem em calha DIN

The LevelOne 24V DC Industrial Power Supply POW-2431 is a DIN-rail mount unit rated at 75W, designed for continuous operation in industrial environments. It accepts a wide AC input range (90–264V), provides regulated 24V DC output and includes protections against overvoltage, overload and short circuit. The compact metal housing (125.2 x 102 x 32 mm) with mint/silver finish is intended for control cabinets and field installations, and the unit is certified to UL508 and TUV EN60950-1 standards with an MTBF of 506,600 hours.

Advantages

The POW-2431 supports universal AC input and delivers stable 24V DC output at up to 75W while maintaining operation across a wide ambient temperature range (-20 to 60 °C) without additional cooling. Built-in protection circuits (over voltage, overload, short circuit) and compliance with safety and EMC standards ensure reliable performance in harsh industrial conditions. Its DIN-rail form factor and compact dimensions simplify mounting and space management within control cabinets.

Suitable for

• Industrial automation control cabinets
• SCADA and PLC power supply
• Field devices and sensors requiring 24V DC
• Communication and network equipment in industrial sites

Key specifications

• Output voltage: 24V DC
• Output power: 75W
• AC input voltage: 90–264V AC
• Operating temperature: -20 to 60 °C (full load)
• MTBF: 506,600 hours
• Dimensions: 125.2 x 102 x 32 mm
• Certifications: UL508, TUV EN60950-1
• Form factor: DIN-rail mount

How to use

Mount the POW-2431 on a standard DIN rail inside a suitable enclosure. Connect the AC input (90–264V) to the designated terminals and the 24V DC output to the load, observing correct polarity. Verify grounding/earth connection according to installation rules and local codes. After powering up, confirm the output voltage and check indicator LEDs (if present) to ensure normal operation. For wiring and detailed terminal assignments follow the manufacturer's installation guide.

Recommendations

Install the unit in a ventilated control cabinet free from excessive dust, corrosive gases and direct water exposure. Keep ambient temperature within the specified -20 to 60 °C range and avoid mounting near strong heat sources. Regularly inspect terminal connections and protective grounding to maintain reliable long-term operation.
