Módulo UPS online DIGITUS 2000VA / 2000W

Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
Módulo UPS online DIGITUS 2000VA / 2000W
505,04 €
PDF
PDF
Stock 2 Código 300091 Modelo DN-170095 Garantia 3 anos

Envios e devoluções

Entrega prevista quarta-feira, 2 de dezembro
Receberá atualizações através do nosso sistema de seguimento detalhado
Opções de pagamento
Cartão bancárioVisaMastercardPayPalApple PayGoogle PayTransferência bancária

Faça uma pergunta – o assistente IA responde de imediato.

Descrição

The OnLine UPS is an ideal backup solution for your demanding power requirements and offers high reliability in various industrial applications.

- High power factor (1.0), a higher active power enables more connected loads, which saves space and reduces costs.
- High efficiency in online mode, higher efficiency means optimized energy management and lower heat dissipation, resulting in energy savings and improved reliability.
- User-friendly LCD screen provides insight into UPS status for easy installation, configuration and operation.
- Compact rack/tower design optimizes the installation space in the rack and enables flexible installation.
- Minimize device downtime with hot-swappable, user-replaceable battery modules that can be replaced during operation.
- External battery modules allow the runtime to be extended.
- High number of outlets (8 x C13) for optimum power distribution to the consumers.
- Various communication interfaces (RS232/USB, parallel port, SNMP slot) enable remote monitoring of the system.
- Automatic battery self-test and fan speed control increase the service life of the components.
- The REPO function (Remote Emergency Power Off) switches the UPS off in the event of an emergency. If an emergency occurs, the REPO switch turns off the rectifier and the inverter and immediately stops the power supply to the load. The UPS stops charging.

The DIGITUS® OnLine UPS is a double-conversion UPS solution that offers first-class power failure protection and continuous power generation in a compact and flexible system. The single-phase UPS operates with high energy efficiency and is ideal for protecting critical infrastructure in both centralized and edge network applications. Scalable runtime options with matching external battery cabinets provide additional flexibility when a longer uninterruptible power supply is required. The user-friendly LCD display and network management capability, including configuration, make this system easy to install and maintain. With market-leading efficiency and unity power factor, the UPS meets your critical application requirements.

Destaques principais
  • Online double conversion system (VFI-SS-111)
  • Input: IEC60320 C20 socket, 208/220/230/240 Vac
  • Output: 8 x IEC60320 C13, max. 10A per socket outlet
  • Nominal system power: 2000 VA / 2000 W, power factor 1.0
  • AC-AC (online VFI) efficiency: 93 %, ECO mode efficiency: 98 %.
  • Internal battery pack can be replaced during operation.
  • Battery: Valve-protected, non-spillable lead-acid battery
  • Battery quantity: 4 x 12V x 9.0 Ah
  • Charging: 4 hours to 90% capacity after full discharge
  • Network connection: Optional SNMP/Webcard (part number DN-170100) enables the UPS to be monitored remotely.
  • Local communication ports: USB, RS-232 (serial), SNMP card (optional), relay card (optional)
  • Emergency Power-off (EPO) contact for switching off the UPS in an emergency
  • Maximum operating temperature: 0 - 40 °C
  • Storage temperature: -25 - 55 °C
  • Relative humidity: 20 - 90% non-condensing
  • Operating altitude: < 1500 m
  • Product dimensions WxDxH (mm): 440 (19") x 460 x 86.5 (2U)
  • Product weight: 19.5 kg
  • Shipping dimensions WxDxH (mm): 560 x 590 x 200
  • Shipping weight: 23.7 kg
  • Safety standards: IEC/EN62040-1,IEC/EN60950-1
  • EMC standards: IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4, IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
  • Optionally available: 19" UPS mounting kit (profile rails), article number DN-170109
  • IP protection class: IP21
  • Heat dissipation: 614 BTU/h
  • Noise level in online mode: approx. 50 dB(A) at a distance of 1 m (may vary slightly depending on load and ambient temperature).

Especificações

Especificações
Altitude de funcionamento
0 - 1500 m
Altura
86.5 mm
Altura da embalagem
200 mm
Cabo de alimentação removível
Sim
Cabos incluídos
RS-232, cabo USB
Capacidade da bateria
9 Ah
Capacidade de potência de saída
1,5 kVA
Código da pauta aduaneira do Reino Unido
85044085
Conector de corte de emergência (EPO)
Sim
Cor do produto
Preto
Corrente máxima
10 A
Eficiência
93%
Eficiência (modo ECO)
98%
Fator de potência
1
Ficha de alimentação
acoplador C20
Formato
Rackmount
Humidade relativa de armazenamento (H-H)
20 - 90%
Humidade relativa de funcionamento (H-H)
20 - 90%
Kit de montagem em rack
Sim
Largura
440 mm
Largura da embalagem
555 mm
Manual
Sim
Número de pilhas suportadas
4
Número de portas série
1
Número de tomadas CA
8 tomadas CA
País de origem
China
Peso
19.5 kg
Peso da embalagem
22.9 kg
Porta USB
Sim
Portas Ethernet LAN (RJ-45)
2
Potência de saída
2000 W
Profundidade
460 mm
Profundidade da embalagem
595 mm
Tamanho (polegadas)
48.3 cm (19")
Temperatura de armazenamento (T-T)
-25 - 55 °C
Temperatura de funcionamento (T-T)
0 - 40 °C
Tempo de recarga da bateria (90%)
4 h
Tensão da bateria
12 V
Tensão de funcionamento de entrada (máx.)
240 V
Tensão de funcionamento de entrada (mín.)
208 V
Tipo de conector USB
USB Type-B
Tipo de ecrã
LCD
Tipo de fonte de energia
AC
Tipo de interface série
RS-232
Tipo de refrigeração
Ativo
Tipos de tomadas
acoplador C13
Topologia da UPS
Dupla conversão (online)
Ventoinha integrada
Sim
Volume da embalagem
66705.5 cm³
