AHD HD-CVI HD-TVI Câmara bullet 2MP APTI-H51V21-36W com visão noturna IR 20m, IP66, objetiva 3,6mm, saída BNC 4-em-1

Traditional analog CCTV systems often struggle with blurry footage, poor low-light performance, and compatibility issues when mixing different camera brands. The APTI-H51V21-36W bullet camera solves these problems by delivering crisp 1080p video over existing coaxial cabling, with support for AHD, HD-CVI, HD-TVI, and CVBS formats — making it a drop-in upgrade for virtually any analog DVR. Its 20-meter infrared illumination and IP66 weatherproof housing ensure reliable surveillance day and night, indoors or outdoors.

Who is it for

This camera is ideal for homeowners, small business owners, and installers who need a cost-effective, high-definition security solution without replacing existing wiring. It suits monitoring entrances, driveways, backyards, warehouses, and retail spaces where clear identification is critical.

Main features

• 2MP CMOS sensor with 1920×1080 resolution for sharp, detailed images.
• 4-in-1 video output (AHD, HD-CVI, HD-TVI, CVBS) for broad DVR compatibility.
• 18 SMD IR LEDs with up to 20m night vision range and ICR cut filter for true day/night switching.
• Fixed 3.6mm lens with approximately 85–90° horizontal field of view.
• IP66-rated metal housing protects against dust and heavy rain.
• On-screen display (OSD) menu for easy image tuning (DWDR, 2D DNR, etc.).
• Simple 12V DC power supply with low power consumption (max 4W).

Specifications

• Image sensor: 1/2.7" CMOS
• Effective pixels: 1920(H) × 1080(V)
• Video output: 1× BNC, switchable AHD/HD-CVI/HD-TVI/CVBS
• Lens: 3.6mm fixed, horizontal angle approx. 85–90°
• IR range: up to 20m, 18× SMD IR LEDs
• Min. illumination: 0.01 Lux (F1.2, AGC ON), 0 Lux with IR
• Digital noise reduction: 2D DNR
• Wide dynamic range: DWDR
• OSD menu: Yes
• Housing: Metal, IP66
• Power: DC 12V, max 4W
• Operating temperature: -20°C to +50°C

Tips

For best results, mount the camera at a height of 2.5–3 meters and angle it slightly downward to avoid direct sunlight or IR reflection. Use a quality 12V DC power supply and ensure the BNC connector is properly sealed with weatherproof tape if installed outdoors. When connecting to a DVR, set the DVR channel to the matching video format (AHD, HD-CVI, or HD-TVI) for optimal picture quality.
