BOOST PUMP 1100W CAM 88/25X HL (MARINA) - bomba de canal lateral autoaspirante 1100W, altura de elevação máx. 48m, caudal 4,8m³/h, 1 polegada BSP, ferro fundido

With a powerful 1100 W motor and a maximum head of 48 metres, this self-priming peripheral pump delivers up to 4.8 m³/h, making it ideal for demanding water transfer and pressure boosting in marine, domestic, and agricultural applications. Its robust cast iron body and Noryl impeller ensure durability, while the self-priming design allows for suction lifts up to 8 metres.

Overview

The BOOST PUMP 1100W CAM 88/25X HL (MARINA) is engineered for reliable performance in clean water systems. Operating on a standard 230 V / 50 Hz supply, it provides consistent pressure and flow for irrigation, water supply, and pressure boosting. The pump features a 1" BSP inlet and outlet for easy integration into existing piping.

What stands out

• High performance: 1100 W motor delivers up to 48 m head and 80 L/min flow.
• Self-priming: lifts water from up to 8 m below, eliminating the need for foot valves in many setups.
• Durable construction: cast iron body and Noryl impeller resist wear and corrosion.
• Reliable sealing: ceramic/graphite mechanical seal ensures leak-free operation.
• Versatile: suitable for marine, domestic, and agricultural use with clean water up to 35 °C.

Technical details

• Power: 1100 W (1.1 kW)
• Voltage: 230 V, Frequency: 50 Hz
• Max flow rate: 4.8 m³/h (80 L/min)
• Max head: 48 m
• Max suction lift: 8 m
• Connections: 1" BSP inlet and outlet
• Pump body: Cast iron; Impeller: Noryl (technopolymer)
• Motor shaft: Stainless steel; Mechanical seal: Ceramic/graphite
• Max liquid temperature: 35 °C
• Max operating pressure: 6 bar
• Protection rating: IP44; Insulation class: F
• Motor type: Asynchronous, closed, externally ventilated
• Self-priming: Yes

Our verdict

A robust and efficient pump that combines high head and flow with self-priming convenience. The cast iron construction and quality components ensure long service life, making it a smart choice for those needing dependable water transfer and pressure boosting.
