Patch panel Tecline 908060 para 24 ligações Keystone, instalação em rack 1U

Tecline Patch Panel 908060 for 24 Keystone Connectors, 1U Rack Mount is a compact rack accessory designed to centralize modular terminations in a 19-inch equipment rack. The panel accepts up to 24 keystone modules, allowing mixed connector types (Ethernet, RJ45, HDMI, or other keystone-format jacks) to be installed in a single 1U space. It supports structured cabling in server rooms, communication cabinets and AV racks where orderly layout, accessibility and straightforward maintenance are required.

Advantages

The panel provides a standardized, space-saving 1U footprint that simplifies cable routing and reduces rack clutter. Its keystone format enables quick installation and replacement of individual jacks without re-terminating entire runs. The front-facing layout offers clear port access for patching and labeling, while the metal construction ensures stable mounting and alignment in a cabinet or rack frame.

Suitable for

Key specifications

How to use

Mount the patch panel into a standard 19-inch rack using the supplied or compatible mounting screws, aligning the panel at the desired U position. Install keystone jacks into the front openings until each snaps into place. Route and terminate cables to the rear side of the keystone jacks according to the jack manufacturer’s termination color code and testing procedures. Label ports on the front panel to match your network documentation. After installation, test each connection with appropriate network or AV testers to verify continuity and signal integrity.

Recommendations

For reliable long-term performance, use compatible keystone jacks and follow recommended cable management practices: avoid tight bends, maintain bend radii, and secure cable bundles with Velcro or cable ties. Keep documentation current and perform periodic testing after any changes to ensure proper connectivity.
