Placa gráfica Inno3D GeForce RTX 5060 Twin X2 OC — 8 GB GDDR7, 128-Bit, PCIe 5.0, 2280 MHz

The Inno3D GeForce RTX 5060 Twin X2 OC is a compact discrete graphics card designed for small form factor builds while delivering modern GPU capabilities. Based on NVIDIA’s Blackwell architecture and featuring the GeForce RTX 5060 processor, this card provides 8 GB of GDDR7 memory on a 128-bit bus, PCI Express 5.0 interface and an overclocked boost frequency. Dual active fans, an optimized heatsink and a multifunctional backplate help manage thermals in dual-slot enclosures. The card supports high-resolution output up to 7680×4320 and current graphics APIs including DirectX 12 Ultimate and OpenGL 4.6.

Advantages

The Twin X2 OC offers a balance of performance, size and thermal design suitable for compact gaming and content-creation systems. GDDR7 memory and a 128-bit memory bus provide improved bandwidth for texture streaming and frame-buffer tasks compared with previous-generation memory types. NVIDIA Blackwell architecture brings hardware-accelerated ray tracing, AI-driven upscaling and latency-reduction technologies such as DLSS and Reflex for smoother gameplay and faster responsiveness. The white dual-slot cooler with detachable fan blades and optimized fin layout aids cooling in tighter cases while the multifunctional backplate supports heat extraction and protects the PCB.

Suitable for

• 1080p and 1440p gaming with ray tracing and DLSS acceleration
• Compact MATX and ITX small-form-factor desktop builds
• Content creation workflows: video editing, 3D rendering and GPU-accelerated effects
• Multi-monitor or high-resolution display setups up to 7680×4320
• Applications that benefit from AI acceleration and hardware ray tracing

Key specifications

• Graphics processor: NVIDIA GeForce RTX 5060 with hardware ray tracing and AI cores
• Memory: 8 GB GDDR7 on a 128-bit memory bus
• Interface: PCI Express 5.0 x16 compatible slot
• Boost clock (factory overclocked): up to approximately 2527 MHz (boost state)
• Maximum digital resolution: up to 7680×4320
• Display outputs: multiple DisplayPort outputs and HDMI output (see manufacturer for exact counts)
• Cooling: dual 88 mm fans, optimized fin spacing, DHT heat spreader and multifunctional backplate
• Power connector: single 8-pin auxiliary power

How to use

Install the card into an available PCIe x16 slot on a compatible motherboard supporting PCIe 5.0 or PCIe 4.0/3.0 backward compatibility. Secure the card in the case using the expansion slot screws and connect the required 8‑pin power cable from the PSU. Attach display cables to the HDMI or DisplayPort outputs and install the latest GeForce drivers from the NVIDIA or Inno3D website. For compact systems, ensure adequate case airflow by positioning intake and exhaust fans to help the Twin X2 OC’s cooling system operate effectively. When using GPU-accelerated applications, enable vendor-recommended settings such as DLSS, hardware ray tracing or application-specific GPU acceleration options.

Recommendations

Use a power supply with sufficient wattage and a dedicated 8-pin connector; keep system drivers up to date; monitor temperatures under load and maintain case airflow to ensure sustained performance in small form factor builds.
