Placa-mãe SAPPHIRE NITRO+ X870EA WIFI7 PhantomLink - AMD X870E, Socket AM5, ATX, suporta Ryzen 9000/8000/7000, DDR5 até 8400MHz (OC), PCIe 5.0, 4x M.2, Wi-Fi 7, 5GbE LAN, Dual USB4

The SAPPHIRE NITRO+ X870EA WIFI7 is a premium AMD X870E ATX motherboard built around the Socket AM5 platform and SAPPHIRE's signature PhantomLink power technology. Designed for high-end gaming rigs and content-creation workstations, it pairs a robust 16+2+1 phase power design with the latest connectivity standards to extract the full potential of AMD Ryzen 9000, 8000 and 7000 series desktop processors.

Advantages

A 16+2+1 phase VRM rated at 90A per phase delivers clean, stable power even under sustained overclocking and heavy multi-threaded workloads. Four DDR5 DIMM slots support up to 256 GB of dual-channel memory at speeds up to 8400 MHz (OC), while quad M.2 slots (two PCIe 5.0 and two PCIe 4.0) with tool-free, quick-release heatsinks make storage upgrades effortless. PhantomLink technology can power compatible BTF-ready graphics cards directly from the board for a clean, cable-free build.

Suitable for

• High-end AMD Ryzen 9000 series gaming systems
• Content creators needing fast NVMe storage and high-capacity DDR5
• Enthusiasts building clean, cable-managed PCs with hidden power connectors
• Overclockers seeking strong VRM headroom and high memory frequencies

Key specifications

• Brand: SAPPHIRE
• Model: NITRO+ X870EA WIFI7 (PhantomLink Edition)
• Chipset: AMD X870E
• CPU socket: Socket AM5
• Compatible CPUs: AMD Ryzen 9000 / 8000 / 7000 Series
• Power delivery: 16+2+1 phase, 90A per phase
• Memory: 4x DDR5 DIMM, dual-channel, up to 256 GB, up to 8400 MHz (OC)
• Expansion: 1x PCIe 5.0 x16, 2x PCIe 4.0 x4
• Storage: 4x M.2 (2x PCIe 5.0 x4, 2x PCIe 4.0 x4), 4x SATA 6Gb/s, RAID 0/1/10
• Rear USB: 2x USB4 40Gbps Type-C, 4x USB 3.2 Gen2 Type-A, 4x USB 3.2 Gen1 Type-A, 2x USB 2.0
• Networking: Realtek RTL8126 5GbE LAN, Wi-Fi 7 (802.11be), Bluetooth 5.4
• Audio: Realtek ALC897 HD Audio, 5.1 channel with S/PDIF
• Display output: 1x HDMI
• Form factor: ATX, 305 x 244 mm
• EAN: 4895106296893

How to use

Install a compatible AMD Ryzen processor into the AM5 socket, populate the DDR5 DIMM slots (enable EXPO in BIOS for rated speeds), and mount NVMe drives under the quick-release M.2 heatsinks. Connect the 24-pin ATX and EPS power on the front edge as usual; for PhantomLink GPU power, route the dedicated 12V connector as described in the manual.

Recommendations

For the cleanest builds, pair this board with a PhantomLink-compatible graphics card to eliminate visible GPU power cabling, and fit Gen5 NVMe SSDs in the PCIe 5.0 M.2 slots to take full advantage of the platform's bandwidth.
