Quadro elétrico de distribuição EFB Elektronik TT Kleinverteiler 2 50DA IP54 190x215x90 mm

The EFB Elektronik TT Kleinverteiler 2 50DA IP54 (190x215x90 mm) is a compact electrical distribution enclosure designed to house miniature circuit breakers and associated wiring in small electrical installations. With IP54 protection, it offers resistance to dust ingress and splash water, making it suitable for indoor areas and sheltered outdoor locations. The enclosure provides a neat, accessible space for organizing distribution, cable entries and connections in residential and light-commercial settings.

Advantages

This distribution enclosure combines compact dimensions with IP54 protection, allowing installation where space is limited but basic environmental protection is required. The internal layout is optimized for easy mounting of standard DIN-rail components and provides sufficient room for cable routing. The robust housing construction reduces the risk of accidental contact with live parts and contributes to safer, more reliable circuit organization.

Suitable for

Key specifications

How to use

Install the enclosure on a suitable flat surface using appropriate fasteners and according to local mounting regulations. Fit the DIN-rail and mount required circuit breakers and protective devices, ensuring correct orientation and secure fastening. Route incoming and outgoing cables through the provided entry points, secure conductors to the devices and verify clearances to the enclosure body. Close the front cover after completing connections and perform electrical testing in accordance with applicable standards and safety procedures.

Recommendations

Use the enclosure in environments consistent with its IP54 rating—avoid direct exposure to heavy rain or continuous high-pressure water jets. Ensure all internal connections are made by a qualified electrician and comply with local electrical codes. For installations requiring higher ingress protection or larger capacity, select a suitably rated enclosure.
