Rittal AX 1304000 caixa compacta, aço inoxidável, 600x600x210 mm, IP66

Industrial control systems demand robust protection against moisture, dust, and mechanical impact. The Rittal AX 1304000 compact enclosure provides a secure, corrosion-resistant housing for electrical and electronic components in demanding environments. Its stainless steel construction and high protection ratings ensure long-term reliability for automation, power distribution, and control applications.

Who is it for

This enclosure is ideal for system integrators, panel builders, and maintenance engineers who need a durable, easy-to-install solution for housing PLCs, drives, terminal blocks, and other sensitive equipment. It suits food processing, pharmaceutical, chemical, and outdoor installations where washdowns or aggressive atmospheres are common.

Main features

• Premium stainless steel 1.4301 (AISI 304) with brushed, grain 240 finish for excellent corrosion resistance and a clean appearance.
• High protection ratings: IP 66 and NEMA 4X, safeguarding against powerful water jets and dust ingress.
• Single door with reversible hinge, opening angle of 130°, and cam lock with 3 mm double-bit insert for secure access.
• Foamed-in PU seal ensures reliable gasketing and long service life.
• Depth-adjustable galvanized mounting plate (2.0 mm thick) for flexible component layout.
• Compact dimensions 600 x 600 x 210 mm (W x H x D) with 1.25 mm wall and door thickness for sturdy construction.
• Wide range of approvals including UL, cUL, TÜV, EAC, Germanischer Lloyd, and VDE for global compliance.

Specifications

• Enclosure type: Compact enclosure
• Material: Stainless steel 1.4301 (AISI 304)
• Surface finish: Brushed, grain 240
• Dimensions (W x H x D): 600 x 600 x 210 mm
• Protection category: IP 66 | NEMA 4X
• Door type: Single door, hinged right (reversible)
• Lock type: Cam lock with 3 mm double-bit insert
• Gasket material: Foamed-in PU seal
• Mounting plate material: Galvanized sheet steel
• Mounting plate thickness: 2.0 mm
• Mounting plate adjustment: Depth-adjustable
• Enclosure wall thickness: 1.25 mm
• Door wall thickness: 1.25 mm
• Door opening angle: 130°
• Approvals: UL, cUL, TÜV, EAC, Germanischer Lloyd, VDE
• Application: Industrial control, automation, power distribution
• Colour: Natural stainless steel

Tips

For outdoor installations, ensure proper cable glands and breather drains to prevent condensation. The reversible door allows field adaptation to left or right opening without extra parts. Use the depth-adjustable mounting plate to optimize space for deep components or wiring ducts.
