Rittal Caixa de Ligação KX, Aço Inoxidável 1.4301, 200x200x120mm, IP66, sem Placa de Montagem 1563000

Terminal box in stainless steel 1.4301 (AISI 304) with brushed finish, grain 400. The enclosure offers IP66 protection and a single hinged door with cam lock (3 mm double-bit insert). A gland plate in the base simplifies cable entry. Without mounting plate.

Advantages

Corrosion-resistant stainless steel enclosure for demanding environments. High protection class IP66 and NEMA 4X. Impact resistance IK08. Single hinged door with secure cam lock. PU foam gasket ensures reliable sealing. Gland plate in the base for flexible cable routing. Surface finish brushed, grain 400, easy to clean.

Suitable for

• Industrial control and automation applications
• Outdoor installations requiring weatherproof enclosures
• Food and beverage industry (hygienic design)
• Chemical and pharmaceutical environments
• Marine and offshore applications

Key specifications

• Material: Stainless Steel 1.4301 (AISI 304)
• Dimensions (W x H x D): 200 x 200 x 120 mm
• Protection: IP66, NEMA 4X, IK08
• Door: Single hinged, cam lock with 3 mm double-bit insert
• Gland plate: Yes, in the base
• Material thickness: Enclosure 1.25 mm, Door 1.25 mm
• Gasket: PU foam
• Mounting plate: Not included
• Approvals: UL, cUL, TÜV, Germanischer Lloyd, RMRS, VDE, CSA, EAC
• Operating temperature: -20 °C to +60 °C

Recommendations

For applications requiring a robust, corrosion-resistant terminal box with high ingress protection. Combine with Rittal mounting plates and accessories for internal component installation.
