Rittal SV 9342.140 Conjunto de montagem, cinzento, profundidade 100 mm, 2 unid.

Rittal SV 9342.140 mounting panel set consists of two grey mounting panels with a depth of 100 mm, designed for installation inside electrical and control enclosures. The panels provide a flat, stable surface for mounting components and cabling in compact cabinets where shallow mounting depth is required. The set includes two identical panels intended to be fixed to the enclosure interior to organize and support equipment.

Advantages

The panels are manufactured to fit standard Rittal enclosure interiors and offer a neat, uniform mounting surface that helps simplify assembly and maintenance. Their shallow 100 mm depth makes them suitable for space-constrained installations while still providing adequate clearance for typical terminal blocks, small controllers and wiring. The grey finish provides a neutral, professional appearance and resists visible dirt in industrial environments.

Suitable for

Key specifications

How to use

Position the panel inside the enclosure at the desired mounting height and secure it to the enclosure using the appropriate screws or fasteners compatible with the enclosure's mounting points. Ensure the panel is level and firmly attached before mounting electrical components. Route wiring and fix devices to the panel using suitable screws, DIN-rail adaptors or standoffs as required. Leave sufficient clearance for ventilation and cable bends according to the installed components' requirements.

Recommendations

Verify compatibility with the enclosure model and mounting points before installation. Use corrosion-resistant fasteners in humid or aggressive environments and follow local electrical and safety standards when mounting live electrical equipment.
