SATEL BE Wave HYBRID 128 Plus central de alarme para ABAX 2, LAN, WiFi, LTE

The SATEL BE Wave HYBRID 128 Plus is a versatile alarm control panel designed for the BE WAVE system, supporting up to 128 zones (wired or wireless). It integrates seamlessly with ABAX 2 wireless devices and offers built-in PSTN dialer, Ethernet (ETHM-1 Plus), and GSM/GPRS communication options. Ideal for residential and commercial security applications, this panel provides advanced features such as voice synthesizer, remote control via SATEL MOBILE apps, and EN 50131 Grade 2/3 compliance.

Advantages

Supports up to 128 zones and 128 outputs, with 32 partitions for flexible area management. Built-in PSTN dialer and optional Ethernet/GSM modules ensure reliable communication. Voice synthesizer for audible alerts. Remote control via smartphone apps (SATEL MOBILE KPD2/GPRS). Easy programming with DLOADX software and firmware updates via USB or Ethernet.

Suitable for

• Residential security systems
• Small to medium commercial premises
• Integration with ABAX 2 wireless devices
• Remote monitoring and control applications

Key specifications

• Max. Zones: 128 (wired or wireless)
• On-board Zones: 16 (expandable)
• Max. Outputs: 128
• On-board Outputs: 8 (4 high-current, 4 low-current)
• Max. Users: 128 + 8 Administrators
• Partitions: 32
• Timers: 64
• Event Log Capacity: 22527 events
• Communication: Built-in PSTN dialer, supports ETHM-1 Plus (Ethernet), GSM-X/GPRS-A (GSM/GPRS)
• Power Supply Input: 18V AC
• Auxiliary Power Output: 2.5 A
• Keypad Support: Up to 8 (LCD, touch screen)
• Expansion Bus: 2 x RS-485
• Wireless System Support: ABAX 2 / ABAX (via ACU-280 / ACU-120)
• Programming Software: DLOADX
• Firmware Update: USB / ETHM-1 Plus
• Voice Synthesizer: Yes
• Security Grade: EN 50131 Grade 2 / Grade 3 (configuration dependent)
• Operating Temperature: -10°C to +55°C
• Remote Control App: SATEL MOBILE KPD2 / SATEL MOBILE GPRS (with modules)

Recommendations

For optimal performance, use with SATEL ABAX 2 wireless detectors and ETHM-1 Plus Ethernet module for remote access. Ensure proper power supply and backup battery for uninterrupted operation.
