Suporte de montagem Rittal 9340.290, caixa de poliamida, branco, largura 10 mm

Rittal 9340.290 is a mounting bracket with a polyamide housing in white, designed for use in equipment racks and electrical enclosures. The bracket has a 10 mm width and a lightweight construction, providing a non-conductive fixing solution for mounting small components, routing cables and attaching accessories inside control cabinets and IT racks. It is compatible with a 10 mm pitch pattern and can be bayed on both sides to extend construction width as required. An integral cable duct is included to support tidy wiring runs.

Advantages

The polyamide housing offers electrical insulation and resistance to common workshop environments while keeping weight low (approximately 60 g). Its 10 mm width and modular design allow precise, space-saving installation in standard pitch patterns. The integral cable duct simplifies cable management and helps maintain organized wiring within the cabinet. The bracket’s neutral white color integrates with typical enclosure interiors.

Suitable for

Key specifications

How to use

Install the bracket into the enclosure or rack at the prescribed 10 mm pitch positions and secure it according to the cabinet’s mounting system. Use the integrated cable duct to route cables through the bracket and position components or accessories along the bracket’s profile. Multiple brackets can be bayed together on either side to achieve the required construction width; ensure all connections are mechanically secure and compatible with the enclosure’s mounting dimensions.

Recommendations

For safe and reliable operation, use the bracket only for lightweight, non-live components or for cable management. Verify mechanical compatibility with the enclosure’s pitch system before installation. Avoid exposure to aggressive chemicals or excessive mechanical loads that could compromise the polyamide housing.
