Synergy21 Ficha RJ45 Cat.6A S-UTP, blindada, cinzento, pack de 100, diâmetro exterior 6,5 mm (S215675)

The Synergy21 RJ45 Cat.6A S-UTP Connector is a high-performance shielded RJ45 plug designed for reliable data transmission in demanding network environments. This pack of 100 connectors is ideal for professional installers and IT technicians requiring consistent, high-quality terminations for S-UTP (Screened Unshielded Twisted Pair) cables. With a maximum outer cable diameter of 6.5 mm, these connectors support 23-26 AWG solid or stranded conductors and are gold-plated for optimal conductivity and corrosion resistance.

Advantages

These connectors offer excellent shielding performance, ensuring minimal electromagnetic interference (EMI) and crosstalk, making them suitable for high-speed networks up to 10 Gigabit Ethernet. The robust polycarbonate housing with UL 94V-0 flammability rating provides durability and safety. Each connector includes a strain relief boot for enhanced cable retention and longevity. With over 750 insertion cycles, they are built for repeated use in patch panels and wall outlets.

Suitable for

• Data centers and server rooms requiring Cat.6A performance
• Structured cabling systems for enterprise networks
• Industrial Ethernet applications where shielding is critical
• Professional network installation and maintenance

Key specifications

• Connector Type: RJ45 Plug
• Performance Standard: Category 6A (Cat.6A)
• Cable Type Compatibility: S-UTP (Screened Unshielded Twisted Pair)
• Shielding: Shielded
• Conductor Configuration: 8P8C
• Contact Plating: Gold-plated (50µm)
• Housing Material: Polycarbonate (PC)
• Color: Grey
• Max Cable Outer Diameter: 6.5 mm
• Pack Quantity: 100 pieces
• Termination Method: Crimp
• Conductor Gauge Compatibility: 23-26 AWG (Solid/Stranded)
• Flammability Rating: UL 94V-0
• Insertion Cycles: >750
• Compliance: RoHS, REACH

Recommendations

For optimal performance, use with Cat.6A S-UTP cable and a compatible crimping tool. Ensure proper termination to maintain shielding integrity. Suitable for use in both residential and commercial network installations.
