TMSS GERMANY Telemecanique Sensors Interruptor fim de curso universal XCKD2118P16, haste de êmbolo, 1 NC + 1 NO, comutação instantânea, IP66/IP67/IP68

Industrial machines need reliable position detection that survives dust, washdowns and millions of cycles. The TMSS GERMANY Telemecanique Sensors XCKD2118P16 universal limit switch delivers exactly that, with a rod plunger actuator and snap-action contacts in a rugged Zamak body.

Who is it for

Maintenance engineers and machine builders who need a compact, durable limit switch for conveyors, machine tools, packaging lines and other automated equipment. It fits where space is tight and conditions are tough.

Main features

• Rod plunger actuator with linear movement for precise end-of-travel detection
• Snap-action contact block with 1 NC + 1 NO for fast, positive switching
• Zamak body with plastic head, rated IP66, IP67 and IP68 for harsh environments
• Screw clamp terminals accept 1 x 0.34 to 2 x 1.5 mm² conductors
• One tapped M16 x 1.5 cable entry for a standard cable gland
• Mechanical durability of 10 million cycles for long service life

Specifications

• Product type: Limit switch
• Series: Telemecanique Sensors XCKD
• Actuator type: Rod plunger
• Movement of operating head: Linear
• Contact configuration: 1 NC + 1 NO
• Contact operation: Snap action
• Number of poles: 2
• Electrical connection: Screw clamp terminals (1 x 0.34...2 x 1.5 mm²)
• Cable entry: 1 entry tapped for M16 x 1.5 cable gland
• Rated insulation voltage: 500 V (IEC), 300 V (UL)
• Rated operational current: 3 A at 240 V AC (AC-15), 0.27 A at 250 V DC (DC-13)
• Enclosure material: Zamak body, plastic head
• Operating temperature: -25 to 70 °C
• Mechanical durability: 10,000,000 cycles
• Mounting: Fixed, body fixing by 2 screws M4
• Short-circuit protection: 10 A cartridge fuse type gG (gl)

Tips

Pair with a suitable M16 cable gland to maintain the IP rating. For DC inductive loads, use a diode or RC snubber across the contacts to extend electrical life.
