Tomada SCHUKO JUNG CD 1520 KINA WW 16 A 250 V com campo de escrita, Safety Plus, duroplasto, série CD, branco alpino

Schuko socket outlet with hinged cover, rated 16 A / 250 V, in Alpine White. The hinged cover provides IP44 protection when closed, making it suitable for damp or outdoor locations. Full plate design from the Jung CD 500 series, flush-mounted with screw terminals.

Advantages

Halogen-free thermoplastic construction, UV-resistant, and VDE certified. The hinged cover protects against splashing water and dust, while the full plate design offers a clean, modern appearance.

Suitable for

• Residential and commercial installations
• Bathrooms, kitchens, and covered outdoor areas
• Flush-mounted boxes with 60 mm diameter

Key specifications

• Socket type: Schuko (Type F)
• Rated current: 16 A
• Rated voltage: 250 V~
• Frequency: 50/60 Hz
• Protection class: IP44 (with hinged cover closed)
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Material: Thermoplastic (PC)
• Colour: Alpine White
• Number of sockets: 1
• Halogen-free: Yes
• Terminal capacity: up to 2.5 mm² (rigid conductors)
• Mounting depth: approx. 32 mm
• Operating temperature: -5 to +40 °C
• Certification: VDE
• UV-resistant: Yes

Recommendations

For installation in damp or outdoor areas, ensure the hinged cover is closed when not in use to maintain IP44 protection. Use with appropriate flush-mounted boxes and rigid conductors up to 2.5 mm².
