Wittenberg Antennen Conjunto de 3 antenas LTE, WLAN, rede móvel, router (K-103522)

This antenna set stands out by combining three omnidirectional antennas with magnetic bases, offering flexible placement for improved LTE, WLAN, and mobile signal reception across multiple frequency bands. Unlike fixed-installation antennas, the magnetic mounts allow quick repositioning on metal surfaces, making it practical for temporary setups or testing different locations.

Highlights

• Three omnidirectional antennas for multi-band coverage
• Magnetic bases for easy placement on metal surfaces
• 2.5 m cables with SMA male connectors for flexible positioning
• Supports LTE, WLAN, UMTS, and GSM frequencies

In daily use

The set is suited for indoor environments where signal strength needs a boost, such as offices, workshops, or homes with weak reception. Each antenna connects directly to devices with SMA female ports, including many LTE routers and WLAN access points. The vertical polarization and 2 dBi gain provide a balanced improvement without excessive directionality, while the RG174 cables offer a practical length for routing away from interference.

Full specifications

• Number of antennas: 3
• Antenna type: Omnidirectional
• Frequency range (LTE): 790-960 MHz, 1710-2170 MHz, 2500-2700 MHz
• Frequency range (WLAN): 2400-2483 MHz
• Frequency range (UMTS/3G): 1900-2170 MHz
• Frequency range (GSM/2G): 900/1800 MHz
• Gain: 2 dBi per antenna
• Connector type: SMA male
• Cable length: 2.5 m per antenna
• Impedance: 50 Ohm
• VSWR: < 2:1
• Polarization: Vertical
• Mounting type: Magnetic base
• Application: Indoor
• Colour: Black
• Cable type: RG174
• Operating temperature: -20°C to +65°C

Final note

A practical three-antenna solution for enhancing wireless connectivity in indoor spaces, with versatile magnetic mounting.
