Wittenberg Antennen LTE GPS Poly-103532 Adaptador SMA - 5 m, Preto

For fleet managers and installers needing reliable connectivity in vehicles, the Wittenberg Antennen LTE GPS Poly-103532 combines LTE and GPS reception in a single low-profile antenna. It mounts with adhesive and connects via two 5 m SMA cables, suitable for telematics, tracking, and mobile data applications.

Key specifications

• Antenna type: Combination LTE/GPS antenna
• LTE frequency bands: 698-960 MHz, 1710-2700 MHz
• GPS frequency band: 1575.42 MHz (L1)
• LTE peak gain: 2 dBi
• GPS LNA gain: 28 dBi
• Impedance: 50 Ohm
• Connector: 2x SMA male
• Cable length: 2x 5 m
• Cable type: RG174
• Mounting: Adhesive (3M pad)
• IP rating: IP67
• Operating temperature: -40°C to +85°C
• Housing material: ABS
• Colour: Black

Why choose it

Dual-function design reduces installation complexity and saves space compared to separate antennas. The integrated GPS LNA ensures strong signal reception even in challenging environments.

Ideal use cases

• Vehicle tracking and fleet management
• Telematics and IoT applications
• Mobile data connectivity for commercial vehicles

Good to know

The antenna is rated IP67 for dust and water resistance, making it suitable for exterior mounting. The adhesive pad provides secure attachment without drilling.
